The high-speed data logger offers 1 ms sampling across up to 120 channels and can be paired with 5 different types of plug-in input units. The input modules measure strain and distortion, making the logger ideal for automotive applications involving the evaluation of vehicle components as well as robotic equipment.
The high-speed data logger offers 1 ms sampling across up to 120 channels and can be paired with 5 different types of plug-in input units. The input modules measure strain and distortion, making the logger ideal for automotive applications involving the evaluation of vehicle components as well as robotic equipment.
Collect data from wireless modules installed in remote or confined locations via a LAN connection with this data logger. New input modules measure strain and distortion, ideal for automotive applications involving the evaluation of vehicle components as well as robotic equipment.
Features
Note: Measurement is not possible with the LR8450 only. One or more plug-in modules are required (sold separately).
| Maximum Number of Connectable Modules | 4 plug-in input modules |
| Connectable Modules | U8550, U8551, U8552, U8553, U8554 |
| Number of Measurement Channels | Up to 120 channels with plug-in input modules |
| Pulse and Logic Input | [Number of channels] 8 channels (common GND, non-isolated, exclusive setting for pulse/logic input for individual channels) [Adaptive input format] Non-voltage contact, open collector, or voltage input [Count] 0 to 1000 M pulse, 1 pulse resolution [Rotational speed] 0 to 5000/n (r/s), 1/n (r/s) resolution, 0 to 300,000/n (r/minute), 1/n (r/minute) resolution, n: Number of pulses per rotation (1 to 1000) [Logic input] Records 1 or 0 for each recording interval |
| Recording Intervals | 1 ms *5, 2 ms *5, 5 ms *5 (*5: Can be set only when using 1 ms/S modules), 10 ms to 1 hour, 22 selections (Data refresh interval can be set for each unit |
| Dimensions | Without any modules: 10.7 x 5.7 x 1.6" (272 x 145 x 43 mm) With 2 modules: 10.7 x 7.8 x 2.4" (272 x 198 x 63 mm) With 4 modules: 10.7 x 9.9 x 2.4" (272 x 252 x 63 mm) |
| Weight | 39.1 oz (1108 g) |
Click on a category to view a selection of compatible accessories with the Hioki LR8450 Memory HiLogger, 120 channels.
