For use with the Ior logger.
For use with the Ior logger.
| Conductor Size | Ø1.6" (40 mm) |
| Rated Current | 10 A (rms) AC (14.1 Apeak) |
| Output Voltage | 500 mV AC/10 A AC |
| Accuracy | ±1% rdg±0.025 mV (40 to 70 Hz) ±4% rdg±0.025 mV (30 Hz to 5 kHz, with inputs of 100 mA or more) |
| Phase Shift | Within 1% (45 to 70 Hz while combining with KEW 5050, under the input of 10% or more of KEW 5050 leakage current range) |
| Cable Length | 9.84' (3 m) |
| Output Connector | MINI DIN 6PIN |
| Applicable Standards | IEC 61010-1, IEC 61010-2-032 CAT III 300V Pollution degree 2, IEC 61326-1 |
| Operating Temperature & Humidity Range | 14 to 122°F (-10 to 50°C) relative humidity 85% or less (no condensation) |
| Weight | 0.68 lb (308.4 g) |
